Axel Wirth Maschinen GmbH have been producing roller applicators since 1986.

The most important tool is here, of course, the application roller. In close cooperation with a roller coating company, rubber surfaces have been developed during many years. Supported by the unique quick dismounting system of the roller applicator, the customer gets a variety of tools and possibilies in his hand. The customer can apply glue, oil, lacquer, stain, lye with a machine thanks to the use of different rollers.

Since "Wirth" roller applicators are often placed beside large scale plants, in order to be able to produce
also special orders, more and more customers contact us and want to use these application rollers of the
"Wirth"-machines also in their large scale plants.
Correspondingly, we now offer also the coating of rollers which customers can also install in other machines than the "Wirth" ones.

Following dimensions are possible:

up to a total length of 6,000 mm
up to a diameter of 850 mm
up to a a total weight of 2.5 tons

What is special about "Wirth" rubber coatings?
Example sponge rubber rollers:
short delivery time: 4 – 6 weeks
high form stability: almost no shrinking even in case of longer exposure time
Variety: "Wirth" offers a lot of different pore sizes in different rubber types
high quality: thanks to most modern production technology, "Wirth" sponge rubber rollers do not have a
base layer.
Competent advice: thanks to long lasting, also practical experience, you obtain an individual advice

Product range comprises:
solid rubber 20° – 98° ShA
polyurethane 55° – 95° ShA
hard rubber 60° – 85° ShD
sponge rubber 5° – 25° ShA
multi-layer rubber

rollers' range of use:
glue applicators
oil applicators
stain applicators
lacquer applicators
feeder rolls
conveyor rolls

roller surfaces can be:
grooved
pored
smooth
rhombic
according to customer's specifications

Your application is not mentioned?

Please contact us!

Looking forward to see you on the Logna 2105 in Hannover: 11.Mai 2015 bis 15.Mai 2015.
hall 11 / booth B33

Ligna 2015
Ligna 2015

The "Wirth" disk roller conveyors consist of a tray in stainless steel
with retainers for up to 7 axles.

On these axles, disks in stainless steel are mounted.

Those disks offer a minimum contact surface after the glue application, so that most of the glue quantity applied stays on the work piece during transport.

After work, disks can easily be removed.

It is also possible to connect several disk roller conveyors continuously.

Application of Cold Glue and Adhesive

Apply cold and liquid glue and glue with “Wirth” glue application machines.

The glue applicators are suitable for the application of cold liquid glue and adhesive, such as dispersion adhesive, white glue, veneer glue, PVAC-glue, Kaurit, Latex, urea resin glue, synthetic resin, Melamine resin, powder glue soluble in water with/without hardener. For the most part the tools are cleaned with water.

Application media with special solvents

This is different for Polyurethane adhesives, PUR, PU, 1KPU, 2KPU, two component glues. These adhesives are to be cleaned with a certain cleansing agent. The kind of rubber on the glue roller is determined as agreed upon.

Wirth covers each of the glue rollers in such a way that they are resistant to the cleansing agent / solvent. The high-quality steel parts represent a special advantage. For cleaning, remove in next to no time the rollers and the glue basin of the compact machine and clean them in the cleansing bath. Dry up the parts and put them back without tools into the machine. The glue waste deposits on the bottom of the bath and the cleansing agent can be reused.

Glue application can be from one side or two sides.

Axel Wirth Maschinen GmbH supplies besides the classical wood working industry also machines for adhesion of brakes, couplings, foam components, coolers, belts, cardboard and packaging industry…..
